| Image Format |
1/3" Sony Super HAD |
| Effective Pixels |
NTSC : 512(H) X 492(V) PAL : 500(H) X 582(V) |
| H.Resolution |
400 TV Lines |
| Min. Illumination |
0.2Lux / F2.0 |
| Power source |
12VDC / 130mA or less |
| Special |
True Day/Night |
O |
| IP Rating |
IP67 |
| Synchronizing system |
Internal |
| Scanning system |
NTSC 525 Lines PAL 625 Lines 2:1 Interlaced |
| Video output |
1.0Vp-p Composite. 75 Ohms |
| S/N ratio |
More than 50dB (AGC Off) |
| Shutter Speed |
NTSC : 1/60~1/100,000 sec PAL : 1/50~100,000 sec |
| Gamma correction |
r=0.45 |
| White Balance |
2100˚K ~ 9100˚K Auto |
| Gain Control |
4dB~30dB Auto |
| Smear Effect |
0.005% |
| MTBF |
80,000 hours |
| Lens |
Standard |
Fixed IRIS : 4~9mm -VF49 |
| Option |
Fixed IRIS : 2.6~6mm -VF26 |
| Operating Temperature |
14˚F ~ 122˚F (-10˚C ~ +50˚C) |
| Humidity |
Within 90% RH |
| Output Terminal |
4 Feet DIY cable with BNC-Female for Video, 2.1mm DC-Jack for Power |
| Measurement (mm) |
32mm(Dia) x 102mm(L) |
| Weight (Approx.g) |
350 |
| Optional True Features |
External Audio |
O | |
|
|
