The S-VDR2000 will meet and/or exceed relevant standards.S-VDR2000 will be type approved by Det Norske Veritas (DNV) As standard the S-VDR2000 is provided with the following interfaces:
• 8 serial lines supporting RS232 and RS485/422,complying with IEC 1162-1/2 inputspecification and NMEA.Protocols from our libraries are supplied free of charge.Please see below.
• Radar interface according to IEC 91996.
• 4 microphone units for recording of bridgeaudio.
•1 channel for recording of VHF.

The VDR2000 meets the IMO Performance Standard A.861(20),the EU Directive 1999/35/EC and the IEC 61996 Test Specifications. VDR2000 is EC type approved (Wheelmark)according to EU Council Directive 96/98/EC of 20 December on Marine Equipment as amended by directive 2002/75/EC.

•8 serial lines supporting RS232 and RS485/422,complying with IEC 1162-1/2 input specification and NMEA.Protocols from our libraries are supplied free of charge.Please see below.

VDR-1000 has been designed to have many standard system interfaces and to be easily reconfigured when there is any specific requirement from the client. VDR-1000 maintains more than 12 hours of voyage data in the protective capsule and more than 30 days of voyage data in the internal hard disk drive

Totem Voyage Data Recorder is a well proven and affordable system. Totem VDR/SVDR fully complies with IMO regulations and is type approved by DNV. Totem VDR is the only VDR with added value benefits to ship owners.

Totem VDR/SVDR Owner Benefits

Owner's copy of data on hard disk: Totem VDR/SVDR navigational records are kept for ONE YEAR on the VDR/SVDR computer hard disk. (Assisting with US customs security requirements, charterers claims etc.)

• Data transfer ashore by remote queries through SATCOM
• Extra monitor with free IBS information: VDR/SVDR monitor displays status of recorded items at all times (Redundant Integrated Bridge System Information).

Based on the real-time embedded operating system of Vxworks, the system is more reliable, handy and adaptable to all kinds of installations on board.With a power of 25W without any ventilation fans, the Main Cabinet Unit body is designed to be closed, no dust to enter. There are many interfaces with PNP function. It can be configured online, with easy access to debug and random real-time monitor function. It is more convenient for data of download.

The system is stable, needless of special person for check. The Main Cabinet Unit is designed to be closed and can work normally even in bad environment .With a system power of only 25W, needless of ventilation, more reliable as a result.The system's spare parts are all self-developed and manufactured, be in strong position to provide the permanent availabilities.You can enjoy these quality and inexpensive products with excellent global service network worldwide.

Fully meets IMO MSC.163(78), IEC 61996-2, IEC-60945,IEC-61162 and other international standards.
Developed and manufactured by COSPAS-SARSAT regulation.
Advanced GPS engine provides faster position(LAT/LON) and precise information.
Easy installation and stability, trustworthy design.
Operation and alarm information are displayed in LCD monitor at the remote device.
Minimum expenses to select various options based on vessel’s type & use.
Protect final record from UV rays, Salt Water, other pollution source (Including automatic release case)

Voyage Data Recorder (VDR) is one of the leading products of the company. Its main function is to make real-time recording and saving, in a safe and recoverable way, of data and information on the physical state of vessel position change, command and control on vessel during the vessel navigation course, which is used to ensure safe navigation and analyze the cause of a navigation accident. It is also known as ＂marine black box＂.

State-of-the-Art Solid State Final Recording Medium Within a Protective Capsule, Offering

High Capacity and Low Cost of Ownership.

 - Storage Capacity Exceeds 12 Hours of Voyage Data

(RADAR, Audio, and Sensor)

- Long Life/Low Operating Power

- Two-Piece Design Allows for Easy Convenient Servicing

and Installation

- Meets or Exceeds all required IEC 61996 and 60945 Test Specifications

- 1.75 GB Solid State Memory (Expandable)

- Custom Designed Underwater Locator Beacon (ULB)

- Ethernet Interface
